New Holland
T4000 Series Utility Tractor Specifications
T4020 T4030 T4040 T4050
New Holland User Manual
MODEL | T4020 | T4030 | T4040 | T4050 |
ENGINE* | ||||
Type | 4 - cycle, diesel | 4-cycle, diesel | 4-cycle, diesel | 4-cycle, diesel |
Make | New Holland | New Holland | New Holland | New Holland |
Model | F5C | F5C | NEF | NEF |
Cylinders / aspiration | ............................ . ................................ | 4 / Turbochargedair to air intercooled.............................................................. | ||
Displacement, cu. in. (L) | 195 (3.2) | 195 (3.2) | 274 (4.5) | 274 (4.5) |
Block type | Parent bore | Parent bore | Parent bore | Parent bore |
Rated speed, RPM | 2300 | 2300 | 2300 | 2300 |
Gross engine horsepower | 64 | 76 | 84 | 95 |
PTO horsepower | 50 | 62 | 70 | 80 |
Emission legislation | Tier III | Tier III | Tier III | Tier III |
FUEL, AIR AND LUBRICATION SYSTEM | ||||
Injection pump | Bosch / rotary | Bosch / rotary | Bosch / rotary | Bosch / rotary |
Fuel filter type ........ | Dual stage fuel filtering system with water/sediment separator followed by a paper filter element cartridge........ | |||
Fuel tank capacity - standard, gal. (L) | Standard – 21.6 (82) | Standard – 21.6 (82) | Standard – 21.6 (82) | Standard – 21.6 (82) |
– Deluxe, gal. (L) | Deluxe – 19.8 (75) | Deluxe – 19.8 (75) | Deluxe – 23.2 (88) | Deluxe – 23.2 (88) |
– SuperSteer™, gal. (L) | N/A | 19.8 (75) | N/A | 23.2 (88) |
Air filter type | Dry / dual element | Dry / dual element | Dry / dual element | Dry / dual element |
Oil and filter services*** | 600 hours | 600 hours | 600 hours | 600 hours |
Muffler | Under hood | Under hood | Under hood | Under hood |
Exhaust outlet, ROPS | Right side of hood | Right side of hood | Right side of hood | Right side of hood |
Exhaust outlet, cab | Right side A - pillar | Right side A-pillar | Right side A-pillar | Right side A-pillar |
ELECTRICAL | ||||
Battery, volts | 12 | 12 | 12 | 12 |
Battery, cca | 730 | 730 | 800 | 800 |
Alternator, amps | 85 | 85 | 120 | 120 |
Cold start aid | Grid heater | Grid heater | Grid heater | Grid heater |
TRANSMISSION | ||||
Choice of transmissions | 16F x 16R Synchro Command transmission with your choice of mechanical shuttle or | |||
....................... | ||||
clutchless power shuttle (all models) | ||||
Clutch type / size (mechanical), in. (mm) ............................................ | Dry / 11 (280) diameter, heavy-duty cerametallic material............................................. | |||
Clutch type / size (electrohydraulic), in. (mm) ........................................................ | Wet / six plates 5.2 (133), organic material ........................................................ | |||
Gears: 2 – 8 mph working range** ............................................................. | 12 x 12 – 7 gears | 16 x 16 – 9 gears .............................................................. | |||
Gears: <1 mph** ............................................................. | 12 x 12 – 0 gears | 16 x 16 – 3 gears .............................................................. | |||
Maximum speed**, mph (kph) ....................................... | 12 x 12 – 18.73 (30.14) | 16 x 16 – 18.73 (30.14) or 23.5 (37.8)........................................ | |||
PTO | ||||
Type | Fully independent | Fully independent | Fully independent | Fully independent |
Base equipment PTO speed, RPM | 540 | 540 | 540 | 540 |
Optional PTO speed, RPM | N/A | N/A | 540/1000 | 540/1000 |
Operator control ................................................................... | T4000 Standard – mechanical.................................................................... | |||
................................................... | T4000 Deluxe / Deluxe Supersteer™ – Servo-assist................................................... | |||
PTO clutch ......................................................... | Dry, mechanical, 11-in. dry, organic plate .......................................................... | |||
Engine speed ............................................................... | 2196 engine rpm at 540 PTO rpm ................................................................ | |||
3-POINT HITCH | ||||
Category | II / I | II / I | II / I | II / I |
Draft sensing .................................................................. | Mechanical, lower link sensing ................................................................... | |||
Std. ASAE lift capacity @ 24 in., lbs. (kg) | 3962 (1800) | 3962 (1800) | 3962 (1800) | 3962 (1800) |
Link arms | Flexible | Flexible | Flexible | Flexible |
Stabilizers | Telescoping | Telescoping | Telescoping | Telescoping |
Upper / lower limit setting | Lift - O - Matic | Lift-O-Matic | Lift-O-Matic | Lift-O-Matic |
